Implementation Guide

MCD Easy Launch Web functionality is provided by embedding card view iFrame.

Embedding Card View​

Web sites providing card data functionality should add card view iframe element.

info

Displayed card data is cleared after 60 seconds.

Environments​

EnvironmentURL
Testhttps://mcd.tst.meawallet.app/easylaunch
Productionhttps://mcd.prd.meawallet.app/easylaunch

Version​

Version number of the card view iFrame is contained in data-version attribute of the <html> element.

<html lang="en" data-version="1.4.2">

Card View version

Single Element​

One iframe element should be embedded to show a single card view.

<iframe src="https://mcd.prd.meawallet.app/easylaunch?var=<RANDOM>&data=<DATA>" title="Bank Card" width="400px" height="225px" frameBorder="0" />

MCD Web Single Element

Masked Data​

MCD Web Single Element MCD Web Single Element

Click to Copy​

MCD Web Single Element MCD Web Single Element

Multiple Elements​

Embedding multiple iframe elements allow to show card data values separately from each other. Specific card data values can be hidden using a dedicated parameter, for example, showEmboss: false. Masked data is also supported when using multiple elements. See Parameters for more details.

MCD Web Multiple Elements MCD Web Multiple Elements

Configuration​

Random value​

Random number value should be passed to var variable or other custom name to avoid browsers caching card data values or style.

const random = Math.random();
console.log(random); // 0.8653711326681759

Data​

Base64 encoded data is passed to data variable.

Example:

info

Replace apiKeyId, apiKey, cardId, uniqueToken values with environment specific data.

Plain JSON
{
  "apiKeyId": "API_KEY_ID",
  "apiKey": "API_KEY",
  "cardId": "123456789",
  "uniqueToken": "001#12345678",
  "fieldNames": "{\"pan\": \"PAN:\", \"emboss\": \"Cardholder:\", \"exp\": \"Expiry:\", \"cvv\": \"CVV:\", \"details\": \"Show Card Details:\", \"clickToCopyText\": \"Click to copy\", \"clickToCopyCopied\": \"Copied to clipboard!\" }",
  "loader": "bars"
}
Base64
eyJhcGlLZXlJZCI6IkFQSV9LRVlfSUQiLCJhcGlLZXkiOiJBUElfS0VZIiwiY2FyZElkIjoiMTIzNDU2Nzg5IiwidW5pcXVlVG9rZW4iOiIwMDEjMTIzNDU2NzgiLCJmaWVsZE5hbWVzIjoie1wicGFuXCI6IFwiUEFOOlwiLCBcImVtYm9zc1wiOiBcIkNhcmRob2xkZXI6XCIsIFwiZXhwXCI6IFwiRXhwaXJ5OlwiLCBcImN2dlwiOiBcIkNWVjpcIn0iLCJsb2FkZXIiOiJiYXJzIn0=
Parameters​
ParameterRequiredDescription
cardIdXCard ID selected by consumer.
uniqueTokenXSecret value generated by the consumer. See Time-based Secret (TOTP) Generation.
apiKeyIdXAPI Key ID (shared by Meawallet).
apiKeyXAPI Key (shared by Meawallet).
fieldNamesString escaped JSON allows to customize card value field names. Empty (no field names) by default.
styleUrlURL to custom style CSS.
loaderStyle of the loader. Available values - bars, dots, spinner, none. dots by default.
classCSS class name to customize specific iFrame, when embedding multiple iFrames.
clickToCopySet to true to enable click to copy value. Shows a tooltip "Click to copy". false by default.
showCopySet to true to show Copy button. false by default.
showCvvSet to false to hide CVV. true by default.
showEmbossSet to false to hide Cardholder. true by default.
showExpirySet to false to hide Expiry. true by default.
showPanSet to false to hide PAN. true by default.
showPreloadedDataSet to true to mask CVV and PAN. Data is revealed for 60 seconds. false by default.

Copy to Clipboard Permission​

Permission clipboard-write should be added to iframe element, when showCopy is set to true to provide value copying. Add allow attribute to iframe element, replace <URL> with Environment URL.

allow="clipboard-write <URL>"

Example:

<iframe src="https://mcd.meawallet.com/easylaunch?var=<RANDOM>&data=<DATA>" title="Bank Card" width="400px" height="225px" frameBorder="0" allow="clipboard-write https://mcd.meawallet.com/easylaunch" />

Non-latin Characters​

Use encode URI function for non-latin characters before passing them into fieldNames property of the configuration.

Example:

encodeURIComponent(fieldTitle)

Styling​

Custom appearance of the card view can be achieved by passing styleUrl to custom CSS hosted on consumer's server.

info

Providing incorrect MIME type for the hosted CSS file can produce Cross-Origin Read Blocking (CORB) error. For example, referring to a raw file on GitHub provides an incorrect MIME type text/plain and produces CORB error.

HTML​

<div id="app" class="mea-easy-launch-app">
  <div class="mea-preloaded-data-overlay">
    <div class="mea-show-card-details">Show Card Details</div>
  </div>
  <div class="mea-easy-launch-container">
    <div class="mea-data mea-pan-result">
      <div class="mea-field-name mea-field-pan-name">PAN:</div>
      <span class="mea-field-value mea-field-pan-value">1234 5678 1234 5678</span>
      <span class="mea-tooltiptext mea-pan-tooltiptext"/>  <-- Element available with parameter "clickToCopy" only.
      <span class="mea-copy-btn mea-pan-copy"/>
    </div>
    <div class="mea-data mea-cardholder-result">
      <div class="mea-field-name mea-field-cardholder-name">Cardholder:</div>
      <span class="mea-field-value mea-field-cardholder-value">Jane Hopkins</span>
      <span class="mea-tooltiptext mea-cardholder-tooltiptext"/>  <-- Element available with parameter "clickToCopy" only.
      <span class="mea-copy-btn mea-cardholder-copy"/>
    </div>
    <div class="mea-data mea-expiry-result">
      <div class="mea-field-name mea-field-expiry-name">Expiry:</div>
      <span class="mea-field-value mea-field-expiry-value">07/27</span>
      <span class="mea-tooltiptext mea-expiry-tooltiptext"/>  <-- Element available with parameter "clickToCopy" only.
      <span class="mea-copy-btn mea-expiry-copy"/>
    </div>
    <div class="mea-data mea-cvv-result">
      <div class="mea-field-name mea-field-cvv-name">CVV:</div>
      <span class="mea-field-value mea-field-cvv-value">123</span>
      <span class="mea-tooltiptext mea-cvv-tooltiptext"/>  <-- Element available with parameter "clickToCopy" only.
      <span class="mea-copy-btn mea-cvv-copy"/>
    </div>
  </div>
</div>

Masked Data​

When using preloadedData parameter, data (PAN and CVV) is masked, and new classes are added in the HTML structure:
<span class="mea-field-value mea-masked-pan mea-field-pan-value">1234 5678 1234 5678</span>
<span class="mea-field-value mea-masked-cvv mea-field-cvv-value">123</span>

Click to Copy​

When using clickToCopy parameter, values can be copied by clicking on them, and new classes are added in the HTML structure:
<span class="mea-field-value mea-tooltip-pan mea-field-pan-value">1234 5678 1234 5678</span>
<span class="mea-field-value mea-tooltip-cvv mea-field-cvv-value">567</span>
<span class="mea-field-value mea-tooltip-expiry mea-field-expiry-value">12/24</span>
<span class="mea-field-value mea-tooltip-cardholder mea-field-cardholder-value">123</span>

CSS​

ClassDescription
mea-easy-launch-containerMain container.
mea-overlay-styleLoader.
mea-dataContainer of card field name and field value.
mea-field-nameField name.
mea-field-valueField value.
mea-copy-btnCopy button.
mea-pan-resultPAN container.
mea-field-pan-namePAN field name.
mea-field-pan-valuePAN value.
mea-pan-copyPAN value copy button.
mea-cardholder-resultCardholder container.
mea-field-cardholder-nameCardholder name.
mea-field-cardholder-valueCardholder value.
mea-cardholder-copyCardholder value copy button.
mea-expiry-resultExpiry container.
mea-field-expiry-nameExpiry name.
mea-field-expiry-valueExpiry value.
mea-expiry-copyExpiry value copy button.
mea-cvv-resultCVV container.
mea-field-cvv-nameCVV name.
mea-field-cvv-valueCVV value.
mea-cvv-copyCVV value copy button.
mea-masked-panMasked PAN.
mea-masked-cvvMasked CVV.
mea-preloaded-data-overlayHover overlay for masked data.
mea-show-card-detailsText and icon of Show Card Details for masked data.
mea-tooltip-panText and tooltip for Click to Copy value.
mea-tooltip-cardholderText and tooltip for Click to Copy value.
mea-tooltip-expiryText and tooltip for Click to Copy value.
mea-tooltip-cvvText and tooltip for Click to Copy value.
mea-tooltip-textText and tooltip for Click to Copy value.
preloaded-data-overlayDeprecated. Use mea-preloaded-data-overlay instead.
show-card-detailsDeprecated. Use mea-show-card-details instead.
card.css
.mea-easy-launch-app .vld-overlay .vld-icon svg {
  fill: white;
}

.mea-easy-launch-app {
  background: rgb(1,143,219);
  background: linear-gradient(30deg, rgba(1,143,219,1) 0%, rgba(249,95,3,1) 95%);
  border-radius: 15px;
  width: 100%;
  height: 100%;
  position: absolute;
  color: white;
}

.mea-easy-launch-container {
  display: flex;
  flex-direction: column;
  height: 100%;
  font-size: 20px;
}
.mea-easy-launch-container .mea-data:nth-child(1) { order: 2; }
.mea-easy-launch-container .mea-data:nth-child(2) { order: 4; }
.mea-easy-launch-container .mea-data:nth-child(3) { order: 3; }
.mea-easy-launch-container .mea-data:nth-child(4) { order: 1; }

.mea-cvv-result {
  text-align: left;
  padding-left: 20px;
  padding-top: 15px;
}

.mea-cardholder-result {
  margin-top: auto;
  padding-left: 20px;
  padding-bottom: 15px;
}

.mea-pan-result {
  padding-top: 45px;
  padding-bottom: 10px;
}

.mea-expiry-result,
.mea-pan-result {
  text-align: center;
}

.mea-copy-btn {
  background-repeat: no-repeat no-repeat;
  background-position: center center;
  background-size: cover;
  height: 21px;
  width: 21px;
  display: inline-block;
  margin-left: 7px;
  margin-top: 3px;
  vertical-align: bottom;
  cursor: pointer;
  filter: invert(100%) sepia(100%) saturate(0%) hue-rotate(104deg) brightness(103%) contrast(103%);
  transition: all .2s ease-in;
}

.mea-copy-btn:hover {
  filter: invert(92%) sepia(9%) saturate(320%) hue-rotate(202deg) brightness(91%) contrast(91%);
}

.mea-copy-btn:active {
  animation: pulse 1s infinite;
}

.mea-preloaded-data-overlay {
  position: absolute;
  width: 100%;
  height: 100%;
}

.mea-preloaded-data-overlay .mea-show-card-details {
  display: none;
}

.mea-show-card-details::before {
  content: ' ';
  background-repeat: no-repeat no-repeat;
  background-position: center center;
  background-size: cover;
  height: 25px;
  width: 25px;
  display: inline-block;
  vertical-align: top;
  margin-right: 10px;
}

.mea-preloaded-data-overlay:hover .mea-show-card-details {
  display: block !important;
  margin: 25% auto 0;
  text-align: center;
  height: 100%;
  font-size: 20px;
  color: #6495ED;
}

.mea-preloaded-data-overlay:hover {
  opacity: 0.7;
  z-index: 1;
  background-color: white;
  cursor: pointer;
  border-radius: 15px;
}

.mea-field-value {
  position: relative;
  display: inline-block;
}

.mea-field-value .mea-tooltiptext {
  visibility: hidden;
  width: 120px;
  bottom: 110%;
  left: 50%;
  margin-left: -60px;
  background-color: black;
  color: #fff;
  text-align: center;
  padding: 5px 0;
  border-radius: 6px;
  position: absolute;
  z-index: 1;
  font-size: 12px;
}

.mea-field-value .mea-tooltiptext::after {
  content: " ";
  position: absolute;
  top: 100%;
  left: 50%;
  margin-left: -5px;
  border-width: 5px;
  border-style: solid;
  border-color: black transparent transparent transparent;
}

.mea-field-value.mea-tooltip-cvv .mea-tooltiptext {
  left: 93%;
  margin-left: 10px;
  bottom: inherit;
}

.mea-field-value.mea-tooltip-cvv .mea-tooltiptext::after {
  top: 30%;
  left: -4%;
  border-color: transparent black transparent transparent;
}

.mea-field-value:hover .mea-tooltiptext {
  visibility: visible;
}

.mea-field-value[class*='mea-tooltip-'] {
  cursor: pointer;
}

@keyframes pulse {
  0% {
    transform: scale(0.95);
  }
  100% {
    transform: scale(1);
  }
}

Multiple Elements​

When using multiple elements a specific iframe element can be customized by configuring class parameter that specifies CSS class to be used for the specific iframe styling. See Data for more details listing all iframe configuration options.

Data (Plain JSON)
{
    ...
    "class": "iframe-1"
    ...
}
card.css
.iframe-1 .mea-pan-result {
    text-align: center;
}

.iframe-2 .mea-cvv-result {
    text-align: right;
}

Events​

Card view iframe emits the following events.

Event Codes​

EventCode
CARD_DATA_LOADING_STARTED2001
STYLE_URL_ADDED2002
LOADER_OVERLAY_REMOVED2003
CARD_DATA_LOADING_SUCCESS2004
CARD_DATA_CLEARED2005
LOADER_OVERLAY_ADDED2006
CARD_DATA_CARDHOLDER_COPIED2007
CARD_DATA_CVV_COPIED2008
CARD_DATA_EXPIRY_COPIED2009
CARD_DATA_PAN_COPIED2010
CARD_DATA_MASKED2011
CARD_DATA_UNMASKED2012
MISSING_PARAMETERS4001
CARD_DATA_LOADING_FAILED4002
CARD_DATA_COPYING_FAILED4003

Event Object​

Event object contains name of the event and code.

{
  "event": "CARD_DATA_LOADING_SUCCESS",
  "code": 2004
}

Listener​

Listener is added by setting onLoad attribute of the iframe element.

<iframe src="https://mcd.meawallet.com/easylaunch?var=<var>&data=<data>" onLoad={this.iFrameEventListener}></iframe>
iFrameEventListener = event => {
  window.addEventListener('message', event => {
    let url = new URL("https://mcd.meawallet.com/easylaunch");
    if (event.origin === url.origin) {
        console.log(event.data);
    }
  }, false);
}
info

Add check for event.origin to handle events emitted only by MCD Easy Launch host. Make sure the correct environment URL is selected.
